CUI Inc. PYB15-Q24-S5-H-T
- Mfg. Part Number
- PYB15-Q24-S5-H-T
- Manufacturer
- CUI Inc.
- Product Category
- DC DC Converters
- Brief Description
- DC/DC CONVERTER 5V 15W CM
- Datasheet Download
- PYB15-Q24-S5-H-T.pdf
Availability of PYB15-Q24-S5-H-T
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 45.44500
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PYB15-Q24-S5-H-T, we specialize in CUI Inc. all series electronic components. PYB15-Q24-S5-H-T can be shipped within 24 hours after order. If you have any demands for PYB15-Q24-S5-H-T, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PYB15-Q24-S5-H-T Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PYB15-Q24-S5-H-T
| Internal Part Number | EIS-PYB15-Q24-S5-H-T | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Reliability Considerations for Power Supplies Power Supply Safety Standards, Agencies and Marks | |
| RoHS Information | PYB15-T Series Cert of Compliance | |
| Standard Package | 40 | |
| Category | Power Supplies - External/Internal (Off-Board) | |
| Family | DC DC Converters | |
| Series | PYB15-T | |
| Packaging | Bulk | |
| Type | Isolated | |
| Voltage - Input | 9 ~ 36 V | |
| Output | 5V | |
| Number of Outputs | 1 | |
| Output - 1 @ Current (Max) | 5 VDC @ 3A | |
| Output - 2 @ Current (Max) | - | |
| Output - 3 @ Current (Max) | - | |
| Output - 4 @ Current (Max) | - | |
| Power (Watts) | 15W | |
| Applications | * | |
| Mounting Type | Chassis Mount | |
| Operating Temperature | -40°C ~ 85°C | |
| Efficiency | 90% | |
| Package / Case | Module | |
| Size / Dimension | 2.99" L x 1.24" W x 0.99" H (76.0mm x 31.5mm x 25.1mm) | |
| Power (Watts) - Max | 15W | |
| Approvals | EN, IEC | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PYB15-Q24-S5-H-T | |
| Related Links | PYB15-Q2, PYB15-Q24-S5-H-T Datasheet, CUI Inc. Distributor | |
PYB15-Q24-S5-H-T Details Description
