CUI Inc. PYB20-Q24-S3-H
- Mfg. Part Number
- PYB20-Q24-S3-H
- Manufacturer
- CUI Inc.
- Product Category
- DC DC Converters
- Brief Description
- DC/DC CONVERTER 3.3V 20W
- Datasheet Download
- PYB20-Q24-S3-H.pdf
Availability of PYB20-Q24-S3-H
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 41.55619
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PYB20-Q24-S3-H, we specialize in CUI Inc. all series electronic components. PYB20-Q24-S3-H can be shipped within 24 hours after order. If you have any demands for PYB20-Q24-S3-H, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PYB20-Q24-S3-H Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PYB20-Q24-S3-H
| Internal Part Number | EIS-PYB20-Q24-S3-H | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Thermal Management of Power Supplies | |
| Standard Package | 42 | |
| Category | Power Supplies - Board Mount | |
| Family | DC DC Converters | |
| Series | PYB20 | |
| Packaging | Bulk | |
| Type | Isolated Module | |
| Number of Outputs | 1 | |
| Voltage - Input (Min) | 9V | |
| Voltage - Input (Max) | 36V | |
| Voltage - Output 1 | 3.3V | |
| Voltage - Output 2 | - | |
| Voltage - Output 3 | - | |
| Current - Output (Max) | 5A | |
| Power (Watts) - Manufacture Series | 20W | |
| Voltage - Isolation | 1.5kV (1500V) | |
| Features | Remote On/Off, OCP, OVP, SCP, UVLO | |
| Mounting Type | Through Hole | |
| Package / Case | 6-DIP Module | |
| Size / Dimension | 2.00" L x 1.00" W x 0.64" H (50.8mm x 25.4mm x 16.3mm) | |
| Operating Temperature | -40°C ~ 85°C | |
| Efficiency | 86% | |
| Power (Watts) - Max | 17W | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PYB20-Q24-S3-H | |
| Related Links | PYB20-Q, PYB20-Q24-S3-H Datasheet, CUI Inc. Distributor | |
