E-Switch R1966DBLKWHTBS
- Mfg. Part Number
- R1966DBLKWHTBS
- Manufacturer
- E-Switch
- Product Category
- Rocker Switches
- Brief Description
- SWITCH ROCKER SPDT 15A 125V
- Datasheet Download
- R1966DBLKWHTBS.pdf
Availability of R1966DBLKWHTBS
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.44020
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of R1966DBLKWHTBS, we specialize in E-Switch all series electronic components. R1966DBLKWHTBS can be shipped within 24 hours after order. If you have any demands for R1966DBLKWHTBS, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- R1966DBLKWHTBS Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
R1966DBLKWHTBS
| Internal Part Number | EIS-R1966DBLKWHTBS | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | R1966 Series RoHS Cert of Compliance | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Rocker Switches | |
| Series | R1966 | |
| Packaging | Bulk | |
| Circuit | SPDT | |
| Switch Function | On-Off-On | |
| Current Rating | 15A (AC) | |
| Voltage Rating - AC | 125V | |
| Voltage Rating - DC | - | |
| Actuator Type | Concave (Curved) | |
| Color - Actuator/Cap | White | |
| Actuator Marking | I O II | |
| Illumination Type, Color | - | |
| Illumination Voltage (Nominal) | - | |
| Mounting Type | Panel Mount, Snap-In | |
| Termination Style | Solder Lug | |
| Ingress Protection | - | |
| Features | - | |
| Panel Cutout Dimensions | Rectangular - 19.40mm x 13.00mm | |
| Operating Temperature | -30°C ~ 65°C | |
| Mechanical Life | 30,000 Cycles | |
| Electrical Life | 10,000 Cycles | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | R1966DBLKWHTBS | |
| Related Links | R1966DB, R1966DBLKWHTBS Datasheet, E-Switch Distributor | |
R1966DBLKWHTBS Details Description
