Renesas Electronics America R5F5631KDDFB#V0

R5F5631KDDFB#V0 picture photo
Mfg. Part Number
R5F5631KDDFB#V0
Manufacturer
Product Category
Embedded - Microcontrollers
Brief Description
IC MCU FLASH
Datasheet Download
R5F5631KDDFB#V0.pdf
Availability of R5F5631KDDFB#V0

Available Quantity

5020 Pieces

Can ship today

Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks

Marketing Price
$ 16.68000
Our Price
Quote by Email

QUANTITY



EIS Components is the stocking Distributor of R5F5631KDDFB#V0, we specialize in Renesas Electronics America all series electronic components. R5F5631KDDFB#V0 can be shipped within 24 hours after order. If you have any demands for R5F5631KDDFB#V0, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
R5F5631KDDFB#V0 Order Process
Add Parts to RFQ form
Submit RFQ
We reply within 24 hours
You confirm order
Payment
Ship out your order
Specifications of R5F5631KDDFB#V0
Internal Part NumberEIS-R5F5631KDDFB#V0
Lead Free Status / RoHS StatusLead free / RoHS Compliant
Moisture Sensitivity Level (MSL)3 (168 Hours)
Production Status (Lifecycle)In Production
ConditionNew & Unused, Original Sealed
Design ResourcesDevelopment Tool Selector
Standard Package1
Category Integrated Circuits (ICs)
FamilyEmbedded - Microcontrollers
SeriesRX600
PackagingTray
Core ProcessorRX
Core Size32-Bit
Speed100MHz
ConnectivityCAN, EBI/EMI, I²C, LIN, SCI, SPI, USB
PeripheralsDMA, LVD, POR, PWM, WDT
Number of I/O111
Program Memory Size2MB (2M x 8)
Program Memory TypeFLASH
EEPROM Size32K x 8
RAM Size192K x 8
Voltage - Supply (Vcc/Vdd)2.7 V ~ 3.6 V
Data ConvertersA/D 8x10b, 21x12b, D/A 2x10b
Oscillator TypeInternal
Operating Temperature-40°C ~ 85°C
Package / Case144-LQFP
Supplier Device Package144-LFQFP (20x20)
Weight0.001 KG
ApplicationEmail for details
Alternative Part (Replacement)R5F5631KDDFB#V0
Related LinksR5F5631, R5F5631KDDFB#V0 Datasheet, Renesas Electronics America Distributor
R5F5631KDDFB#V0 Details Description
