Renesas Electronics America R5F571MGDDLK#20
- Mfg. Part Number
- R5F571MGDDLK#20
- Manufacturer
- Renesas Electronics America
- Product Category
- Embedded - Microcontrollers
- Brief Description
- IC MCU 512KBIT 2.5MB FLASH
- Datasheet Download
- R5F571MGDDLK#20.pdf
Availability of R5F571MGDDLK#20
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 22.00000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of R5F571MGDDLK#20, we specialize in Renesas Electronics America all series electronic components. R5F571MGDDLK#20 can be shipped within 24 hours after order. If you have any demands for R5F571MGDDLK#20, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- R5F571MGDDLK#20 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
R5F571MGDDLK#20
| Internal Part Number | EIS-R5F571MGDDLK#20 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Development Tool Selector | |
| Standard Package | 1 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - Microcontrollers | |
| Series | RX71M | |
| Packaging | Tray | |
| Core Processor | RXv2 | |
| Core Size | 32-Bit | |
| Speed | 240MHz | |
| Connectivity | CAN, EBI/EMI, Ethernet, I²C, MMC/SD, QSPI, SCI, SPI, SSI, USB OTG | |
| Peripherals | DMA, LVD, POR, PWM, WDT | |
| Number of I/O | 111 | |
| Program Memory Size | 2.5MB (2.5M x 8) | |
| Program Memory Type | FLASH | |
| EEPROM Size | 64K x 8 | |
| RAM Size | 512K x 8 | |
| Voltage - Supply (Vcc/Vdd) | 2.7 V ~ 3.6 V | |
| Data Converters | A/D 8x12b, 21x12b, D/A 2x12 | |
| Oscillator Type | Internal | |
| Operating Temperature | -40°C ~ 85°C | |
| Package / Case | 145-TFLGA | |
| Supplier Device Package | 145-TFLGA (7x7) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | R5F571MGDDLK#20 | |
| Related Links | R5F571M, R5F571MGDDLK#20 Datasheet, Renesas Electronics America Distributor | |
