Schaffner EMC Inc. RB8522-16-3M0
- Mfg. Part Number
- RB8522-16-3M0
- Manufacturer
- Schaffner EMC Inc.
- Product Category
- Common Mode Chokes
- Brief Description
- FIXED IND 3MH 16A 8.4 MOHM TH
- Datasheet Download
- RB8522-16-3M0.pdf
Availability of RB8522-16-3M0
Available Quantity
5240 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 9.69580
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of RB8522-16-3M0, we specialize in Schaffner EMC Inc. all series electronic components. RB8522-16-3M0 can be shipped within 24 hours after order. If you have any demands for RB8522-16-3M0, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- RB8522-16-3M0 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
RB8522-16-3M0
| Internal Part Number | EIS-RB8522-16-3M0 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | RB Series EMC/EMI Chokes | |
| Standard Package | 20 | |
| Category | Filters | |
| Family | Common Mode Chokes | |
| Series | RB | |
| Packaging | Bulk | |
| Filter Type | Power Line | |
| Number of Lines | 2 | |
| Inductance | 3mH | |
| Current | 16A | |
| DC Resistance (DCR) | 8.4 mOhm | |
| Impedance | - | |
| Operating Temperature | -40°C ~ 125°C | |
| Mounting Type | Through Hole | |
| Size / Dimension | 1.969" L x 1.709" W (50.0mm x 43.4mm) | |
| Height (Max) | 2.283" (58.00mm) | |
| Package / Case | Vertical, 8 PC Pin | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | RB8522-16-3M0 | |
| Related Links | RB8522, RB8522-16-3M0 Datasheet, Schaffner EMC Inc. Distributor | |
