Recom Power REC3.5-0509DRW/R8/C
- Mfg. Part Number
- REC3.5-0509DRW/R8/C
- Manufacturer
- Recom Power
- Product Category
- DC DC Converters
- Brief Description
- CONV DC/DC 3.5W 4.5-9VIN +/-09VO
- Datasheet Download
- REC3.5-0509DRW/R8/C.pdf
Availability of REC3.5-0509DRW/R8/C
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 37.31200
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of REC3.5-0509DRW/R8/C, we specialize in Recom Power all series electronic components. REC3.5-0509DRW/R8/C can be shipped within 24 hours after order. If you have any demands for REC3.5-0509DRW/R8/C, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- REC3.5-0509DRW/R8/C Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
REC3.5-0509DRW/R8/C
| Internal Part Number | EIS-REC3.5-0509DRW/R8/C | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | High-isolation DC/DC Converters in Medical and IGBT Application High Isolation Medical Grade DC-DC Converters High Isolation Medical Grade DC-DC Converters | |
| Standard Package | 15 | |
| Category | Power Supplies - Board Mount | |
| Family | DC DC Converters | |
| Series | ECONOLINE REC3.5/R | |
| Packaging | Tube | |
| Type | Isolated Module | |
| Number of Outputs | 2 | |
| Voltage - Input (Min) | 4.5V | |
| Voltage - Input (Max) | 9V | |
| Voltage - Output 1 | 9V | |
| Voltage - Output 2 | -9V | |
| Voltage - Output 3 | - | |
| Current - Output (Max) | 194mA, 194mA | |
| Power (Watts) - Manufacture Series | 3.5W | |
| Voltage - Isolation | 8kV (8000V) | |
| Features | SCP | |
| Mounting Type | Through Hole | |
| Package / Case | 24-DIP Module (9 Leads) | |
| Size / Dimension | 1.26" L x 0.80" W x 0.40" H (32.0mm x 20.3mm x 10.2mm) | |
| Operating Temperature | -40°C ~ 85°C | |
| Efficiency | 80% | |
| Power (Watts) - Max | 3.5W | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | REC3.5-0509DRW/R8/C | |
| Related Links | REC3.5-05, REC3.5-0509DRW/R8/C Datasheet, Recom Power Distributor | |
REC3.5-0509DRW/R8/C Details Description
