Linear REF01CN8
- Mfg. Part Number
- REF01CN8
- Manufacturer
- Linear
- Product Category
- PMIC - Voltage Reference
- Brief Description
- IC VREF SERIES 10V 8DIP
- Datasheet Download
- REF01CN8.pdf
Availability of REF01CN8
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.16074
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of REF01CN8, we specialize in Linear all series electronic components. REF01CN8 can be shipped within 24 hours after order. If you have any demands for REF01CN8, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- REF01CN8 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
REF01CN8
| Internal Part Number | EIS-REF01CN8 | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Voltage Reference Basics | |
| Standard Package | 50 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Voltage Reference | |
| Series | - | |
| Packaging | Tube | |
| Reference Type | Series | |
| Output Type | Fixed | |
| Voltage - Output (Min/Fixed) | 10V | |
| Voltage - Output (Max) | - | |
| Current - Output | 20mA | |
| Tolerance | ±1% | |
| Temperature Coefficient | 65ppm/°C | |
| Noise - 0.1Hz to 10Hz | 30µVp-p | |
| Noise - 10Hz to 10kHz | - | |
| Voltage - Input | 8 V ~ 30 V | |
| Current - Supply | 1.6mA | |
| Current - Cathode | - | |
| Operating Temperature | 0°C ~ 70°C (TA) | |
| Mounting Type | Through Hole | |
| Package / Case | 8-DIP (0.300", 7.62mm) | |
| Supplier Device Package | 8-PDIP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | REF01CN8 | |
| Related Links | REF0, REF01CN8 Datasheet, Linear Distributor | |
REF01CN8 Details Description
