Fairchild Semiconductor RGF1M
- Mfg. Part Number
- RGF1M
- Manufacturer
- Fairchild Semiconductor
- Product Category
- Diodes, Rectifiers - Single
- Brief Description
- DIODE GEN PURP 1KV 1A SMA
- Datasheet Download
- RGF1M.pdf
Availability of RGF1M
Available Quantity
20020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.06887
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of RGF1M, we specialize in Fairchild Semiconductor all series electronic components. RGF1M can be shipped within 24 hours after order. If you have any demands for RGF1M, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- RGF1M Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
RGF1M
| Internal Part Number | EIS-RGF1M | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Assembly/Origin | Additional Manufacturing Source 01/Oct/2014 | |
| Standard Package | 7,500 | |
| Category | Discrete Semiconductor Products | |
| Family | Diodes, Rectifiers - Single | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Diode Type | Standard | |
| Voltage - DC Reverse (Vr) (Max) | 1000V (1kV) | |
| Current - Average Rectified (Io) | 1A | |
| Voltage - Forward (Vf) (Max) @ If | 1.3V @ 1A | |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) | |
| Reverse Recovery Time (trr) | 500ns | |
| Current - Reverse Leakage @ Vr | 5µA @ 1000V | |
| Capacitance @ Vr, F | 8.5pF @ 4V, 1MHz | |
| Mounting Type | Surface Mount | |
| Package / Case | DO-214AC, SMA | |
| Supplier Device Package | SMA (DO-214AC) | |
| Operating Temperature - Junction | -65°C ~ 175°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | RGF1M | |
| Related Links | RG, RGF1M Datasheet, Fairchild Semiconductor Distributor | |
RGF1M Details Description
