TE Connectivity Corcom Filters RJ45-8L1-S
- Mfg. Part Number
- RJ45-8L1-S
- Manufacturer
- TE Connectivity Corcom Filters
- Product Category
- Modular Connectors - Jacks
- Brief Description
- CONN MOD JACK 8P8C R/A SHIELDED
- Datasheet Download
- RJ45-8L1-S.pdf
Availability of RJ45-8L1-S
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of RJ45-8L1-S, we specialize in TE Connectivity Corcom Filters all series electronic components. RJ45-8L1-S can be shipped within 24 hours after order. If you have any demands for RJ45-8L1-S, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- RJ45-8L1-S Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
RJ45-8L1-S
| Internal Part Number | EIS-RJ45-8L1-S | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Modular Jack Portfolio | |
| Featured Product | TE Connectivity - Modular Jack Modular Jack Connectors | |
| Standard Package | 100 | |
| Category | Connectors, Interconnects | |
| Family | Modular Connectors - Jacks | |
| Series | L | |
| Packaging | Bulk | |
| Connector Type | Jack | |
| Number of Positions/Contacts | 8p8c (RJ45, Ethernet) | |
| Number of Ports | 1 | |
| Number of Rows | 1 | |
| Mounting Type | Through Hole | |
| Orientation | 90° Angle (Right) | |
| Termination | Solder | |
| Shielding | Shielded, EMI Finger | |
| Ratings | - | |
| Features | Board Guide, Filter | |
| LED Color | Does Not Contain LED | |
| Ingress Protection | - | |
| Tab Direction | Down | |
| Contact Material | Phosphor Bronze | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 50µin (1.27µm) | |
| Housing Material | Polyester, Glass Filled | |
| Operating Temperature | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | RJ45-8L1-S | |
| Related Links | RJ45-, RJ45-8L1-S Datasheet, TE Connectivity Corcom Filters Distributor | |
RJ45-8L1-S Details Description
