Renesas Electronics America RJH60F6BDPQ-A0#T0
- Mfg. Part Number
- RJH60F6BDPQ-A0#T0
- Manufacturer
- Renesas Electronics America
- Product Category
- IGBTs - Single
- Brief Description
- IGBT 600V 85A 297.6W TO-247A
- Datasheet Download
- RJH60F6BDPQ-A0#T0.pdf
Availability of RJH60F6BDPQ-A0#T0
Available Quantity
5051 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.14520
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of RJH60F6BDPQ-A0#T0, we specialize in Renesas Electronics America all series electronic components. RJH60F6BDPQ-A0#T0 can be shipped within 24 hours after order. If you have any demands for RJH60F6BDPQ-A0#T0, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- RJH60F6BDPQ-A0#T0 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
RJH60F6BDPQ-A0#T0
| Internal Part Number | EIS-RJH60F6BDPQ-A0#T0 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 1 | |
| Category | Discrete Semiconductor Products | |
| Family | IGBTs - Single | |
| Series | - | |
| Packaging | Tube | |
| IGBT Type | Trench | |
| Voltage - Collector Emitter Breakdown (Max) | 600V | |
| Current - Collector (Ic) (Max) | 85A | |
| Current - Collector Pulsed (Icm) | - | |
| Vce(on) (Max) @ Vge, Ic | 1.75V @ 15V, 45A | |
| Power - Max | 297.6W | |
| Switching Energy | - | |
| Input Type | Standard | |
| Gate Charge | - | |
| Td (on/off) @ 25°C | 58ns/131ns | |
| Test Condition | 400V, 30A, 5 Ohm, 15V | |
| Reverse Recovery Time (trr) | 25ns | |
| Package / Case | TO-247-3 | |
| Mounting Type | Through Hole | |
| Supplier Device Package | TO-247A | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | RJH60F6BDPQ-A0#T0 | |
| Related Links | RJH60F6B, RJH60F6BDPQ-A0#T0 Datasheet, Renesas Electronics America Distributor | |
