Renesas Electronics America RJP60D0DPM-00#T1
- Mfg. Part Number
- RJP60D0DPM-00#T1
- Manufacturer
- Renesas Electronics America
- Product Category
- IGBTs - Single
- Brief Description
- IGBT 600V 45A 40W TO-3PFM
- Datasheet Download
- RJP60D0DPM-00#T1.pdf
Availability of RJP60D0DPM-00#T1
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.66500
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of RJP60D0DPM-00#T1, we specialize in Renesas Electronics America all series electronic components. RJP60D0DPM-00#T1 can be shipped within 24 hours after order. If you have any demands for RJP60D0DPM-00#T1, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- RJP60D0DPM-00#T1 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
RJP60D0DPM-00#T1
| Internal Part Number | EIS-RJP60D0DPM-00#T1 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 1 | |
| Category | Discrete Semiconductor Products | |
| Family | IGBTs - Single | |
| Series | - | |
| Packaging | Tube | |
| IGBT Type | - | |
| Voltage - Collector Emitter Breakdown (Max) | 600V | |
| Current - Collector (Ic) (Max) | 45A | |
| Current - Collector Pulsed (Icm) | - | |
| Vce(on) (Max) @ Vge, Ic | 2.2V @ 15V, 22A | |
| Power - Max | 40W | |
| Switching Energy | - | |
| Input Type | Standard | |
| Gate Charge | 45nC | |
| Td (on/off) @ 25°C | 35ns/90ns | |
| Test Condition | 300V, 22A, 5 Ohm, 15V | |
| Reverse Recovery Time (trr) | - | |
| Package / Case | TO-3PFM, SC-93-3 | |
| Mounting Type | Through Hole | |
| Supplier Device Package | TO-3PFM | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | RJP60D0DPM-00#T1 | |
| Related Links | RJP60D0D, RJP60D0DPM-00#T1 Datasheet, Renesas Electronics America Distributor | |
