Schaffner EMC Inc. RN214-1.2-02
- Mfg. Part Number
- RN214-1.2-02
- Manufacturer
- Schaffner EMC Inc.
- Product Category
- Common Mode Chokes
- Brief Description
- CHOKE COMPENSATED 10MH 1.2A VERT
- Datasheet Download
- RN214-1.2-02.pdf
Availability of RN214-1.2-02
Available Quantity
5680 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.39650
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of RN214-1.2-02, we specialize in Schaffner EMC Inc. all series electronic components. RN214-1.2-02 can be shipped within 24 hours after order. If you have any demands for RN214-1.2-02, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- RN214-1.2-02 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
RN214-1.2-02
| Internal Part Number | EIS-RN214-1.2-02 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | RN Choke Series | |
| Featured Product | RFI Suppression Chokes RN Series Chokes | |
| Standard Package | 25 | |
| Category | Filters | |
| Family | Common Mode Chokes | |
| Series | RN | |
| Packaging | Tray | |
| Filter Type | Power Line | |
| Number of Lines | 2 | |
| Inductance | 10mH | |
| Current | 1.2A | |
| DC Resistance (DCR) | 200 mOhm | |
| Impedance | - | |
| Operating Temperature | -40°C ~ 125°C | |
| Mounting Type | Through Hole | |
| Size / Dimension | 0.906" L x 0.610" W (23.00mm x 15.50mm) | |
| Height (Max) | 0.996" (25.30mm) | |
| Package / Case | Vertical, 4 PC Pin | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | RN214-1.2-02 | |
| Related Links | RN214-, RN214-1.2-02 Datasheet, Schaffner EMC Inc. Distributor | |
RN214-1.2-02 Details Description
