Vishay/Dale RN55E9530DB14
- Mfg. Part Number
- RN55E9530DB14
- Manufacturer
- Vishay/Dale
- Product Category
- Through Hole Resistors
- Brief Description
- RES 953 OHM 1/8W .5% AXIAL
- Datasheet Download
- RN55E9530DB14.pdf
Availability of RN55E9530DB14
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.15500
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of RN55E9530DB14, we specialize in Vishay/Dale all series electronic components. RN55E9530DB14 can be shipped within 24 hours after order. If you have any demands for RN55E9530DB14, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- RN55E9530DB14 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
RN55E9530DB14
| Internal Part Number | EIS-RN55E9530DB14 | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 100 | |
| Category | Resistors | |
| Family | Through Hole Resistors | |
| Series | Military, MIL-R-10509/7, RN55 | |
| Packaging | Bulk | |
| Resistance (Ohms) | 953 | |
| Tolerance | ±0.5% | |
| Power (Watts) | 0.125W, 1/8W | |
| Composition | Metal Film | |
| Features | Flame Retardant Coating, Military, Moisture Resistant, Safety | |
| Temperature Coefficient | ±25ppm/°C | |
| Package / Case | Axial | |
| Supplier Device Package | Axial | |
| Size / Dimension | 0.090" Dia x 0.240" L (2.29mm x 6.10mm) | |
| Height | - | |
| Number of Terminations | 2 | |
| Failure Rate | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | RN55E9530DB14 | |
| Related Links | RN55E9, RN55E9530DB14 Datasheet, Vishay/Dale Distributor | |
RN55E9530DB14 Details Description
