Recom Power RNM-1509S
- Mfg. Part Number
- RNM-1509S
- Manufacturer
- Recom Power
- Product Category
- DC DC Converters
- Brief Description
- CONV DC/DC 1W 15VIN 09VOUT
- Datasheet Download
- RNM-1509S.pdf
Availability of RNM-1509S
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 6.38400
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of RNM-1509S, we specialize in Recom Power all series electronic components. RNM-1509S can be shipped within 24 hours after order. If you have any demands for RNM-1509S, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- RNM-1509S Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
RNM-1509S
| Internal Part Number | EIS-RNM-1509S | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 60 | |
| Category | Power Supplies - Board Mount | |
| Family | DC DC Converters | |
| Series | ECONOLINE RNM | |
| Packaging | Tube | |
| Type | Isolated Module | |
| Number of Outputs | 1 | |
| Voltage - Input (Min) | 13.5V | |
| Voltage - Input (Max) | 16.5V | |
| Voltage - Output 1 | 9V | |
| Voltage - Output 2 | - | |
| Voltage - Output 3 | - | |
| Current - Output (Max) | 111mA | |
| Power (Watts) - Manufacture Series | 1W | |
| Voltage - Isolation | 1kV (1000V) | |
| Features | SCP | |
| Mounting Type | Through Hole | |
| Package / Case | 6-DIP Module (4 Leads) | |
| Size / Dimension | 0.33" L x 0.33" W x 0.27" H (8.3mm x 8.3mm x 6.8mm) | |
| Operating Temperature | -40°C ~ 85°C | |
| Efficiency | 78% | |
| Power (Watts) - Max | 1W | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | RNM-1509S | |
| Related Links | RNM-, RNM-1509S Datasheet, Recom Power Distributor | |
RNM-1509S Details Description
