C&K Components RS014R05A0PAGY
- Mfg. Part Number
- RS014R05A0PAGY
- Manufacturer
- C&K Components
- Product Category
- Tactile Switches
- Brief Description
- SWITCH TACTILE SPST-NO 0.05A 12V
- Datasheet Download
- RS014R05A0PAGY.pdf
Availability of RS014R05A0PAGY
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.09135
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of RS014R05A0PAGY, we specialize in C&K Components all series electronic components. RS014R05A0PAGY can be shipped within 24 hours after order. If you have any demands for RS014R05A0PAGY, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- RS014R05A0PAGY Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
RS014R05A0PAGY
| Internal Part Number | EIS-RS014R05A0PAGY | |
| Lead Free Status / RoHS Status | Vendor undefined / Vendor undefined | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 500 | |
| Category | Switches | |
| Family | Tactile Switches | |
| Series | RS, COMAX | |
| Packaging | Bulk | |
| Circuit | SPST-NO | |
| Switch Function | Off-Mom | |
| Contact Rating @ Voltage | 0.05A @ 12VDC | |
| Actuator Type | Standard | |
| Mounting Type | Through Hole | |
| Actuator Height off PCB, from Pins | 4.30mm | |
| Actuator Orientation | Top Actuated | |
| Termination Style | PC Pin | |
| Outline | 6.00mm x 6.00mm | |
| Illumination | Non-Illuminated | |
| Illumination Voltage (Nominal) | - | |
| Illumination Type, Color | - | |
| Operating Force | 130gf | |
| Ingress Protection | - | |
| Features | - | |
| Actuator Material | Polybutylene Terephthalate (PBT) | |
| Switch Travel | 0.25mm | |
| Mechanical Life | 100,000 Cycles | |
| Operating Temperature | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | RS014R05A0PAGY | |
| Related Links | RS014R0, RS014R05A0PAGY Datasheet, C&K Components Distributor | |
