Honeywell Sensing and Productivity Solutions RTY090HVNBX
- Mfg. Part Number
- RTY090HVNBX
- Manufacturer
- Honeywell Sensing and Productivity Solutions
- Product Category
- Position Sensors - Angle, Linear Position Measuring
- Brief Description
- SENSOR HALL EFFECT ROTARY
- Datasheet Download
- RTY090HVNBX.pdf
Availability of RTY090HVNBX
Available Quantity
5025 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 28.68750
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of RTY090HVNBX, we specialize in Honeywell Sensing and Productivity Solutions all series electronic components. RTY090HVNBX can be shipped within 24 hours after order. If you have any demands for RTY090HVNBX, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- RTY090HVNBX Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
RTY090HVNBX
| Internal Part Number | EIS-RTY090HVNBX | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Design/Specification | RTY Series Material Change 12/Feb/2015 | |
| Standard Package | 1 | |
| Category | Sensors, Transducers | |
| Family | Position Sensors - Angle, Linear Position Measuring | |
| Series | RTY | |
| For Measuring | Rotary Position | |
| Technology | Hall Effect | |
| Rotation Angle - Electrical, Mechanical | 90° (±45°), Continuous | |
| Linear Range | - | |
| Output | Analog Voltage | |
| Output Signal | Clockwise Increase | |
| Actuator Type | Flatted Shaft | |
| Linearity | ±1% | |
| Resistance (Ohms) | - | |
| Resistance Tolerance | - | |
| Voltage - Supply | 10 V ~ 30 V | |
| Mounting Type | Chassis Mount | |
| Termination Style | Connector | |
| Operating Temperature | -40°C ~ 125°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | RTY090HVNBX | |
| Related Links | RTY09, RTY090HVNBX Datasheet, Honeywell Sensing and Productivity Solutions Distributor | |
RTY090HVNBX Details Description
