API Delevan S1210R-393F
- Mfg. Part Number
- S1210R-393F
- Manufacturer
- API Delevan
- Product Category
- Fixed Inductors
- Brief Description
- FIXED IND 39UH 179MA 5 OHM SMD
- Datasheet Download
- S1210R-393F.pdf
Availability of S1210R-393F
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.29200
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of S1210R-393F, we specialize in API Delevan all series electronic components. S1210R-393F can be shipped within 24 hours after order. If you have any demands for S1210R-393F, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- S1210R-393F Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
S1210R-393F
| Internal Part Number | EIS-S1210R-393F | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 2,000 | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Series | S1210R | |
| Packaging | Tape & Reel (TR) | |
| Type | - | |
| Material - Core | Ferrite | |
| Inductance | 39µH | |
| Tolerance | ±1% | |
| Current Rating | 179mA | |
| Current - Saturation | - | |
| Shielding | Shielded | |
| DC Resistance (DCR) | 5 Ohm Max | |
| Q @ Freq | 40 @ 2.5MHz | |
| Frequency - Self Resonant | 12MHz | |
| Operating Temperature | -55°C ~ 125°C | |
| Frequency - Test | 2.5MHz | |
| Mounting Type | Surface Mount | |
| Package / Case | 1210 (3225 Metric) | |
| Size / Dimension | 0.138" L x 0.105" W (3.51mm x 2.66mm) | |
| Height - Seated (Max) | 0.101" (2.57mm) | |
| Supplier Device Package | 1210 (3225 Metric) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | S1210R-393F | |
| Related Links | S1210, S1210R-393F Datasheet, API Delevan Distributor | |
S1210R-393F Details Description
