Omron Automation & Safety S8JX-G30012CD
- Mfg. Part Number
- S8JX-G30012CD
- Manufacturer
- Omron Automation & Safety
- Product Category
- AC DC Converters
- Brief Description
- AC/DC CONVERTER 12V 300W
- Datasheet Download
- S8JX-G30012CD.pdf
Availability of S8JX-G30012CD
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 326.47000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of S8JX-G30012CD, we specialize in Omron Automation & Safety all series electronic components. S8JX-G30012CD can be shipped within 24 hours after order. If you have any demands for S8JX-G30012CD, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- S8JX-G30012CD Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
S8JX-G30012CD
| Internal Part Number | EIS-S8JX-G30012CD | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Design/Specification | S8JX-G Series Plating Aug/2013 | |
| Standard Package | 1 | |
| Category | Power Supplies - External/Internal (Off-Board) | |
| Family | AC DC Converters | |
| Series | S8JX-G | |
| Type | Enclosed | |
| Number of Outputs | 1 | |
| Voltage - Input | 85 ~ 264 VAC | |
| Voltage - Output 1 | 12V | |
| Voltage - Output 2 | - | |
| Voltage - Output 3 | - | |
| Voltage - Output 4 | - | |
| Current - Output (Max) | 27A | |
| Power (Watts) | 300W | |
| Applications | ITE (Commercial) | |
| Voltage - Isolation | - | |
| Efficiency | 75% | |
| Operating Temperature | -10°C ~ 60°C | |
| Features | Load Sharing, Universal Input | |
| Mounting Type | DIN Rail | |
| Size / Dimension | 8.06" L x 4.33" W x 3.78" H (204.8mm x 110.0mm x 96.0mm) | |
| Minimum Load Required | - | |
| Approvals | CE | |
| Power (Watts) - Max | 300W | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | S8JX-G30012CD | |
| Related Links | S8JX-G, S8JX-G30012CD Datasheet, Omron Automation & Safety Distributor | |
S8JX-G30012CD Details Description
