Kingbright SC08-21CGKWA
- Mfg. Part Number
- SC08-21CGKWA
- Manufacturer
- Kingbright
- Product Category
- Display Modules - LED Character and Numeric
- Brief Description
- DISPLAY 570NM GRN 1DIG 0.8 TH
- Datasheet Download
- SC08-21CGKWA.pdf
Availability of SC08-21CGKWA
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.09200
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SC08-21CGKWA, we specialize in Kingbright all series electronic components. SC08-21CGKWA can be shipped within 24 hours after order. If you have any demands for SC08-21CGKWA, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SC08-21CGKWA Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SC08-21CGKWA
| Internal Part Number | EIS-SC08-21CGKWA | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 20 | |
| Category | Optoelectronics | |
| Family | Display Modules - LED Character and Numeric | |
| Series | - | |
| Number of Characters | 1 | |
| Size / Dimension | 0.984" H x 0.732" W x 0.417" D (25.00mm x 18.60mm x 10.60mm) | |
| Digit/Alpha Size | 0.80" (20.32mm) | |
| Display Type | 7-Segment | |
| Common Pin | Common Cathode | |
| Color | Green | |
| Voltage - Forward (Vf) (Typ) | 2.1V | |
| Current - Test | 20mA | |
| Millicandela Rating | 25mcd | |
| Wavelength - Peak | 574nm | |
| Power Dissipation (Max) | 75mW | |
| Package / Case | 18-DIP (0.600", 15.24mm), 13 Leads | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SC08-21CGKWA | |
| Related Links | SC08-2, SC08-21CGKWA Datasheet, Kingbright Distributor | |
SC08-21CGKWA Details Description
