NXP Semiconductors/Freescale Semiconductor, Inc. SC16IS760IPW-T
- Mfg. Part Number
- SC16IS760IPW-T
- Manufacturer
- NXP Semiconductors/Freescale Semiconductor, Inc.
- Product Category
- Interface - UARTs (Universal Asynchronous Receiver Transmitter)
- Brief Description
- IC UART I2C/SPI 24-TSSOP
- Datasheet Download
- SC16IS760IPW-T.pdf
Availability of SC16IS760IPW-T
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.99500
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SC16IS760IPW-T, we specialize in NXP Semiconductors/Freescale Semiconductor, Inc. all series electronic components. SC16IS760IPW-T can be shipped within 24 hours after order. If you have any demands for SC16IS760IPW-T, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SC16IS760IPW-T Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SC16IS760IPW-T
| Internal Part Number | EIS-SC16IS760IPW-T | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 2,500 | |
| Category | Integrated Circuits (ICs) | |
| Family | Interface - UARTs (Universal Asynchronous Receiver Transmitter) | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Features | - | |
| Number of Channels | 1, UART | |
| FIFO's | 64 Byte | |
| Protocol | RS232, RS485 | |
| Voltage - Supply | 2.5V, 3.3V | |
| With Parallel Port | - | |
| With Auto Flow Control | Yes | |
| With IrDA Encoder/Decoder | - | |
| With False Start Bit Detection | Yes | |
| With Modem Control | Yes | |
| With CMOS | - | |
| Mounting Type | Surface Mount | |
| Package / Case | 24-TSSOP (0.173", 4.40mm Width) | |
| Supplier Device Package | 24-TSSOP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SC16IS760IPW-T | |
| Related Links | SC16IS7, SC16IS760IPW-T Datasheet, NXP Semiconductors/Freescale Semiconductor, Inc. Distributor | |
