Semtech SC644ULTRT
- Mfg. Part Number
- SC644ULTRT
- Manufacturer
- Semtech
- Product Category
- PMIC - LED Drivers
- Brief Description
- IC LED Driver DC DC Regulator 25mA Backlight 20-MLPQ-UT (3x3)
- Datasheet Download
- SC644ULTRT.pdf
Availability of SC644ULTRT
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.38373
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SC644ULTRT, we specialize in Semtech all series electronic components. SC644ULTRT can be shipped within 24 hours after order. If you have any demands for SC644ULTRT, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SC644ULTRT Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SC644ULTRT
| Internal Part Number | EIS-SC644ULTRT | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Lighting Product Selector | |
| Standard Package | 3,000 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - LED Drivers | |
| Series | SemPulse® | |
| Packaging | Tape & Reel (TR) | |
| Type | DC DC Regulator | |
| Topology | Switched Capacitor (Charge Pump) | |
| Internal Switch(s) | Yes | |
| Number of Outputs | 6 | |
| Voltage - Supply (Min) | 2.9V | |
| Voltage - Supply (Max) | 5.5V | |
| Voltage - Output | 2.5 V ~ 5.25 V | |
| Current - Output / Channel | 25mA | |
| Frequency | - | |
| Dimming | - | |
| Applications | Backlight | |
| Operating Temperature | -40°C ~ 85°C (TA) | |
| Mounting Type | Surface Mount | |
| Package / Case | 20-UFQFN Exposed Pad | |
| Supplier Device Package | 20-MLPQ-UT (3x3) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SC644ULTRT | |
| Related Links | SC644, SC644ULTRT Datasheet, Semtech Distributor | |
SC644ULTRT Details Description
