Amphenol Pcd SCM071000L
- Mfg. Part Number
- SCM071000L
- Manufacturer
- Amphenol Pcd
- Product Category
- Terminal Blocks - Wire to Board
- Brief Description
- CONN TERM BLK 7POS 5.08MM R/A BK
- Datasheet Download
- SCM071000L.pdf
Availability of SCM071000L
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.59200
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SCM071000L, we specialize in Amphenol Pcd all series electronic components. SCM071000L can be shipped within 24 hours after order. If you have any demands for SCM071000L, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SCM071000L Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SCM071000L
| Internal Part Number | EIS-SCM071000L | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 25 | |
| Category | Connectors, Interconnects | |
| Family | Terminal Blocks - Wire to Board | |
| Series | SCM | |
| Packaging | Tray | |
| Number of Levels | 1 | |
| Positions Per Level | 7 | |
| Pitch | 0.200" (5.08mm) | |
| Mating Orientation | Horizontal with Board | |
| Current | 20A | |
| Voltage | 300V | |
| Wire Gauge | 12-28 AWG | |
| Mounting Type | Through Hole | |
| Wire Termination | Screwless - Spring Cage, Tension Clamp | |
| Features | Interlocking (Side), Lever Actuated | |
| Color | Black | |
| Operating Temperature | 125°C | |
| Housing Material | Polyamide (PA), Nylon | |
| Contact Material - Plating | Brass - Tin Plated | |
| Clamp Material - Plating | Steel, Stainless | |
| Screw Material - Plating | - | |
| Torque - Screw | - | |
| Screw Thread | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SCM071000L | |
| Related Links | SCM07, SCM071000L Datasheet, Amphenol Pcd Distributor | |
SCM071000L Details Description
