Delta Electronics SD02S1212A
- Mfg. Part Number
- SD02S1212A
- Manufacturer
- Delta Electronics
- Product Category
- DC DC Converters
- Brief Description
- DCDC CONVERTER 12VOUT 2W
- Datasheet Download
- SD02S1212A.pdf
Availability of SD02S1212A
Available Quantity
5056 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 10.26700
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SD02S1212A, we specialize in Delta Electronics all series electronic components. SD02S1212A can be shipped within 24 hours after order. If you have any demands for SD02S1212A, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SD02S1212A Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SD02S1212A
| Internal Part Number | EIS-SD02S1212A | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 2 (1 Year) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Industrial DC/DC Converters Overview | |
| Featured Product | Industrial DC-DC Converters Power Management Solutions | |
| Standard Package | 10 | |
| Category | Power Supplies - Board Mount | |
| Family | DC DC Converters | |
| Series | SD02S/D | |
| Packaging | Tube | |
| Type | Isolated Module | |
| Number of Outputs | 1 | |
| Voltage - Input (Min) | 9V | |
| Voltage - Input (Max) | 18V | |
| Voltage - Output 1 | 12V | |
| Voltage - Output 2 | - | |
| Voltage - Output 3 | - | |
| Current - Output (Max) | 167mA | |
| Power (Watts) - Manufacture Series | 2W | |
| Voltage - Isolation | 1.5kV (1500V) | |
| Features | SCP, UVLO | |
| Mounting Type | Surface Mount | |
| Package / Case | 16-SMD Module | |
| Size / Dimension | 0.94" L x 0.71" W x 0.31" H (23.9mm x 18.1mm x 8.0mm) | |
| Operating Temperature | -40°C ~ 85°C | |
| Efficiency | 80% | |
| Power (Watts) - Max | 2W | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SD02S1212A | |
| Related Links | SD02S, SD02S1212A Datasheet, Delta Electronics Distributor | |
