C&K Components SD07H0SK
- Mfg. Part Number
- SD07H0SK
- Manufacturer
- C&K Components
- Product Category
- DIP Switches
- Brief Description
- SWITCH DIP TAPE SEALED 7POS SMD
- Datasheet Download
- SD07H0SK.pdf
Availability of SD07H0SK
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SD07H0SK, we specialize in C&K Components all series electronic components. SD07H0SK can be shipped within 24 hours after order. If you have any demands for SD07H0SK, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SD07H0SK Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SD07H0SK
| Internal Part Number | EIS-SD07H0SK | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 25 | |
| Category | Switches | |
| Family | DIP Switches | |
| Series | SD | |
| Packaging | Tube | |
| Circuit | SPST | |
| Number of Positions | 7 | |
| Current Rating | 100mA | |
| Voltage Rating | 25VDC | |
| Actuator Type | Slide (Standard) | |
| Actuator Level | Flush, Recessed | |
| Contact Material | Copper Alloy | |
| Contact Finish | Gold | |
| Height Above Board | 0.170" (4.33mm) | |
| Mounting Type | Surface Mount | |
| Termination Style | Gull Wing | |
| Pitch | 0.100" (2.54mm), Full | |
| Washable | Yes | |
| Features | Tape Seal | |
| Body Material | Polyphthalamide (PPA) | |
| Length | 0.758" (19.25mm) | |
| Operating Temperature | -40°C ~ 85°C | |
| Mechanical Life | 2,000 Cycles | |
| Electrical Life | 2,000 Cycles | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SD07H0SK | |
| Related Links | SD07, SD07H0SK Datasheet, C&K Components Distributor | |
SD07H0SK Details Description
