Bourns Inc. SDR1105-270ML
- Mfg. Part Number
- SDR1105-270ML
- Manufacturer
- Bourns Inc.
- Product Category
- Fixed Inductors
- Brief Description
- FIXED IND 27UH 2.8A 90 MOHM SMD
- Datasheet Download
- SDR1105-270ML.pdf
Availability of SDR1105-270ML
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.28560
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SDR1105-270ML, we specialize in Bourns Inc. all series electronic components. SDR1105-270ML can be shipped within 24 hours after order. If you have any demands for SDR1105-270ML, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SDR1105-270ML Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SDR1105-270ML
| Internal Part Number | EIS-SDR1105-270ML | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | SDR1105 Series Material Declaration | |
| PCN Assembly/Origin | Magnetic products Oct/2013 | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 800 | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Series | Automotive, AEC-Q200, SRR1280A | |
| Packaging | Tape & Reel (TR) | |
| Type | Wirewound | |
| Material - Core | Ferrite | |
| Inductance | 27µH | |
| Tolerance | ±20% | |
| Current Rating | 2.8A | |
| Current - Saturation | 5A | |
| Shielding | Unshielded | |
| DC Resistance (DCR) | 90 mOhm Max | |
| Q @ Freq | - | |
| Frequency - Self Resonant | - | |
| Operating Temperature | -40°C ~ 125°C | |
| Frequency - Test | 1kHz | |
| Mounting Type | Surface Mount | |
| Package / Case | Nonstandard | |
| Size / Dimension | 0.437" L x 0.394" W (11.10mm x 10.00mm) | |
| Height - Seated (Max) | 0.197" (5.00mm) | |
| Supplier Device Package | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SDR1105-270ML | |
| Related Links | SDR110, SDR1105-270ML Datasheet, Bourns Inc. Distributor | |
SDR1105-270ML Details Description
