Bourns Inc. SDR6603-821M
- Mfg. Part Number
- SDR6603-821M
- Manufacturer
- Bourns Inc.
- Product Category
- Fixed Inductors
- Brief Description
- FIXED IND 820UH 100MA 12.6 OHM
- Datasheet Download
- SDR6603-821M.pdf
Availability of SDR6603-821M
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.37440
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SDR6603-821M, we specialize in Bourns Inc. all series electronic components. SDR6603-821M can be shipped within 24 hours after order. If you have any demands for SDR6603-821M, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SDR6603-821M Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SDR6603-821M
| Internal Part Number | EIS-SDR6603-821M | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | SDR6603 Material Declaration | |
| PCN Assembly/Origin | Magnetic products Oct/2013 | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 600 | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Series | SDR6603 | |
| Packaging | Tape & Reel (TR) | |
| Type | Wirewound | |
| Material - Core | Ferrite | |
| Inductance | 820µH | |
| Tolerance | ±20% | |
| Current Rating | 100mA | |
| Current - Saturation | 120mA | |
| Shielding | Unshielded | |
| DC Resistance (DCR) | 12.6 Ohm Max | |
| Q @ Freq | 40 @ 796kHz | |
| Frequency - Self Resonant | 2.5MHz | |
| Operating Temperature | -40°C ~ 125°C | |
| Frequency - Test | 100kHz | |
| Mounting Type | Surface Mount | |
| Package / Case | Nonstandard | |
| Size / Dimension | 0.260" L x 0.175" W (6.60mm x 4.45mm) | |
| Height - Seated (Max) | 0.115" (2.92mm) | |
| Supplier Device Package | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SDR6603-821M | |
| Related Links | SDR660, SDR6603-821M Datasheet, Bourns Inc. Distributor | |
