Vishay Semiconductor/Opto Division SFH6702
- Mfg. Part Number
- SFH6702
- Manufacturer
- Vishay Semiconductor/Opto Division
- Product Category
- Optoisolators - Logic Output
- Brief Description
- OPTOISO 5.3KV PUSH PULL 8DIP
- Datasheet Download
- SFH6702.pdf
Availability of SFH6702
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.78650
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SFH6702, we specialize in Vishay Semiconductor/Opto Division all series electronic components. SFH6702 can be shipped within 24 hours after order. If you have any demands for SFH6702, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SFH6702 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SFH6702
| Internal Part Number | EIS-SFH6702 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 2,000 | |
| Category | Isolators | |
| Family | Optoisolators - Logic Output | |
| Series | - | |
| Packaging | Tube | |
| Number of Channels | 1 | |
| Inputs - Side 1/Side 2 | 1/0 | |
| Voltage - Isolation | 5300Vrms | |
| Common Mode Transient Immunity (Min) | 1kV/µs | |
| Input Type | DC | |
| Output Type | Push-Pull, Totem Pole | |
| Current - Output / Channel | 25mA | |
| Data Rate | 5MBd | |
| Propagation Delay tpLH / tpHL (Max) | 300ns, 300ns | |
| Rise / Fall Time (Typ) | 40ns, 10ns | |
| Voltage - Forward (Vf) (Typ) | 1.6V | |
| Current - DC Forward (If) (Max) | 10mA | |
| Voltage - Supply | 4.5 V ~ 15 V | |
| Operating Temperature | -40°C ~ 85°C | |
| Mounting Type | Through Hole | |
| Package / Case | 8-DIP (0.300", 7.62mm) | |
| Supplier Device Package | 8-DIP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SFH6702 | |
| Related Links | SFH, SFH6702 Datasheet, Vishay Semiconductor/Opto Division Distributor | |
SFH6702 Details Description
