Microsemi Commercial Components SMBG5355A/TR13
- Mfg. Part Number
- SMBG5355A/TR13
- Manufacturer
- Microsemi Commercial Components
- Product Category
- Diodes - Zener - Single
- Brief Description
- DIODE ZENER 18V 5W SMBG
- Datasheet Download
- SMBG5355A/TR13.pdf
Availability of SMBG5355A/TR13
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.55610
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SMBG5355A/TR13, we specialize in Microsemi Commercial Components all series electronic components. SMBG5355A/TR13 can be shipped within 24 hours after order. If you have any demands for SMBG5355A/TR13, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SMBG5355A/TR13 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SMBG5355A/TR13
| Internal Part Number | EIS-SMBG5355A/TR13 | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 3,000 | |
| Category | Discrete Semiconductor Products | |
| Family | Diodes - Zener - Single | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Voltage - Zener (Nom) (Vz) | 18V | |
| Tolerance | ±10% | |
| Power - Max | 5W | |
| Impedance (Max) (Zzt) | 2.5 Ohm | |
| Current - Reverse Leakage @ Vr | 500nA @ 13V | |
| Voltage - Forward (Vf) (Max) @ If | 1.2V @ 1A | |
| Operating Temperature | -65°C ~ 150°C | |
| Mounting Type | Surface Mount | |
| Package / Case | DO-215AA, SMB Gull Wing | |
| Supplier Device Package | SMBG (DO-215AA) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SMBG5355A/TR13 | |
| Related Links | SMBG535, SMBG5355A/TR13 Datasheet, Microsemi Commercial Components Distributor | |
SMBG5355A/TR13 Details Description
