Vishay Semiconductor/Diodes Division SMCJ36C-E3/9AT
- Mfg. Part Number
- SMCJ36C-E3/9AT
- Manufacturer
- Vishay Semiconductor/Diodes Division
- Product Category
- TVS - Diodes
- Brief Description
- TVS DIODE 36VWM 64.3VC SMC
- Datasheet Download
- SMCJ36C-E3/9AT.pdf
Availability of SMCJ36C-E3/9AT
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SMCJ36C-E3/9AT, we specialize in Vishay Semiconductor/Diodes Division all series electronic components. SMCJ36C-E3/9AT can be shipped within 24 hours after order. If you have any demands for SMCJ36C-E3/9AT, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SMCJ36C-E3/9AT Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SMCJ36C-E3/9AT
| Internal Part Number | EIS-SMCJ36C-E3/9AT | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 3,500 | |
| Category | Circuit Protection | |
| Family | TVS - Diodes | |
| Series | TransZorb® | |
| Packaging | Tape & Reel (TR) | |
| Type | Zener | |
| Unidirectional Channels | - | |
| Bidirectional Channels | 1 | |
| Voltage - Reverse Standoff (Typ) | 36V | |
| Voltage - Breakdown (Min) | 40V | |
| Voltage - Clamping (Max) @ Ipp | 64.3V | |
| Current - Peak Pulse (10/1000µs) | 23.3A | |
| Power - Peak Pulse | 1500W (1.5kW) | |
| Power Line Protection | No | |
| Applications | General Purpose | |
| Capacitance @ Frequency | - | |
| Operating Temperature | -55°C ~ 150°C (TJ) | |
| Mounting Type | Surface Mount | |
| Package / Case | DO-214AB, SMC | |
| Supplier Device Package | DO-214AB (SMCJ) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SMCJ36C-E3/9AT | |
| Related Links | SMCJ36C, SMCJ36C-E3/9AT Datasheet, Vishay Semiconductor/Diodes Division Distributor | |
SMCJ36C-E3/9AT Details Description
