Microsemi Commercial Components SMLJ48CAE3/TR13
- Mfg. Part Number
- SMLJ48CAE3/TR13
- Manufacturer
- Microsemi Commercial Components
- Product Category
- TVS - Diodes
- Brief Description
- TVS DIODE 48VWM 77.4VC SMCJ
- Datasheet Download
- SMLJ48CAE3/TR13.pdf
Availability of SMLJ48CAE3/TR13
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.24200
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SMLJ48CAE3/TR13, we specialize in Microsemi Commercial Components all series electronic components. SMLJ48CAE3/TR13 can be shipped within 24 hours after order. If you have any demands for SMLJ48CAE3/TR13, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SMLJ48CAE3/TR13 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SMLJ48CAE3/TR13
| Internal Part Number | EIS-SMLJ48CAE3/TR13 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 3,000 | |
| Category | Circuit Protection | |
| Family | TVS - Diodes | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Type | Zener | |
| Unidirectional Channels | - | |
| Bidirectional Channels | 1 | |
| Voltage - Reverse Standoff (Typ) | 48V | |
| Voltage - Breakdown (Min) | 53.3V | |
| Voltage - Clamping (Max) @ Ipp | 77.4V | |
| Current - Peak Pulse (10/1000µs) | 38.8A | |
| Power - Peak Pulse | 300W | |
| Power Line Protection | No | |
| Applications | General Purpose | |
| Capacitance @ Frequency | - | |
| Operating Temperature | -55°C ~ 150°C (TJ) | |
| Mounting Type | Surface Mount | |
| Package / Case | DO-214AB, SMC | |
| Supplier Device Package | DO-214AB | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SMLJ48CAE3/TR13 | |
| Related Links | SMLJ48C, SMLJ48CAE3/TR13 Datasheet, Microsemi Commercial Components Distributor | |
SMLJ48CAE3/TR13 Details Description
