Amphenol RF SMP-FS-C07
- Mfg. Part Number
- SMP-FS-C07
- Manufacturer
- Amphenol RF
- Product Category
- Coaxial Connectors (RF)
- Brief Description
- CONN SMP JACK STR 50 OHM SOLDER
- Datasheet Download
- SMP-FS-C07.pdf
Availability of SMP-FS-C07
Available Quantity
5258 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 12.62300
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SMP-FS-C07, we specialize in Amphenol RF all series electronic components. SMP-FS-C07 can be shipped within 24 hours after order. If you have any demands for SMP-FS-C07, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SMP-FS-C07 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SMP-FS-C07
| Internal Part Number | EIS-SMP-FS-C07 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| 3D Model | SMP-FS-C07.igs | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Coaxial Connectors (RF) | |
| Series | - | |
| Packaging | Bulk | |
| Connector Style | SMP | |
| Connector Type | Plug, Female Socket | |
| Contact Termination | Solder | |
| Shield Termination | Solder | |
| Impedance | 50 Ohm | |
| Mounting Type | Free Hanging (In-Line) | |
| Cable Group | RG-405 (.085", .086" Semi Rigid) | |
| Fastening Type | Push-Pull | |
| Frequency - Max | 26.5GHz | |
| Features | - | |
| Housing Color | Gold | |
| Ingress Protection | - | |
| Body Material | Beryllium Copper | |
| Body Finish | Gold | |
| Center Contact Material | Beryllium Copper | |
| Center Contact Plating | Gold | |
| Dielectric Material | Polytetrafluoroethylene (PTFE) | |
| Voltage Rating | 500V | |
| Operating Temperature | -65°C ~ 165°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SMP-FS-C07 | |
| Related Links | SMP-F, SMP-FS-C07 Datasheet, Amphenol RF Distributor | |
