Switchcraft Inc. SN70C12A
- Mfg. Part Number
- SN70C12A
- Manufacturer
- Switchcraft Inc.
- Product Category
- Barrel - Audio Connectors
- Brief Description
- CONN PHONE JACK 2COND SGL CLOSED
- Datasheet Download
- SN70C12A.pdf
Availability of SN70C12A
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 6.93800
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SN70C12A, we specialize in Switchcraft Inc. all series electronic components. SN70C12A can be shipped within 24 hours after order. If you have any demands for SN70C12A, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SN70C12A Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SN70C12A
| Internal Part Number | EIS-SN70C12A | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | Switchcraft RoHS Info | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Barrel - Audio Connectors | |
| Series | SN70C | |
| Packaging | - | |
| Connector Type | Phone Jack | |
| Gender | Female | |
| Signal Lines | Mono | |
| Plug/Mating Plug Diameter | 6.35mm (0.250", 1/4") - Headphone | |
| Number of Positions/Contacts | 2 Conductors, 3 Contacts | |
| Internal Switch(s) | Single Switch | |
| Mounting Type | Through Hole, Right Angle | |
| Termination | Solder | |
| Shielding | Unshielded | |
| Features | Mounting Hardware, Thread Lock | |
| Color - Contact | Silver | |
| Contact Material | Brass | |
| Contact Material - Plating | Nickel | |
| Housing Material | Thermoplastic | |
| Housing Color | Black | |
| Operating Temperature | - | |
| Voltage - Rated | - | |
| Current Rating | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SN70C12A | |
| Related Links | SN70, SN70C12A Datasheet, Switchcraft Inc. Distributor | |
SN70C12A Details Description
