Texas Instruments SN74HCT244PWT
- Mfg. Part Number
- SN74HCT244PWT
- Manufacturer
- Texas Instruments
- Product Category
- Logic - Buffers, Drivers, Receivers, Transceivers
- Brief Description
- IC BUFF/DVR TRI-ST DUAL 20TSSOP
- Datasheet Download
- SN74HCT244PWT.pdf
Availability of SN74HCT244PWT
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.38250
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SN74HCT244PWT, we specialize in Texas Instruments all series electronic components. SN74HCT244PWT can be shipped within 24 hours after order. If you have any demands for SN74HCT244PWT, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SN74HCT244PWT Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SN74HCT244PWT
| Internal Part Number | EIS-SN74HCT244PWT | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 250 | |
| Category | Integrated Circuits (ICs) | |
| Family | Logic - Buffers, Drivers, Receivers, Transceivers | |
| Series | 74HCT | |
| Packaging | Tape & Reel (TR) | |
| Logic Type | Buffer/Line Driver, Non-Inverting | |
| Number of Elements | 2 | |
| Number of Bits per Element | 4 | |
| Current - Output High, Low | 6mA, 6mA | |
| Voltage - Supply | 4.5 V ~ 5.5 V | |
| Operating Temperature | -40°C ~ 85°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 20-TSSOP (0.173", 4.40mm Width) | |
| Supplier Device Package | 20-TSSOP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SN74HCT244PWT | |
| Related Links | SN74HC, SN74HCT244PWT Datasheet, Texas Instruments Distributor | |
SN74HCT244PWT Details Description
