Texas Instruments SN75LBC172A16DWRG4
.jpg)
- Mfg. Part Number
- SN75LBC172A16DWRG4
- Manufacturer
- Texas Instruments
- Product Category
- Interface - Drivers, Receivers, Transceivers
- Brief Description
- IC QUAD RS-485 DIFF DRVR 16-SOIC
- Datasheet Download
- SN75LBC172A16DWRG4.pdf
Availability of SN75LBC172A16DWRG4
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.38070
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SN75LBC172A16DWRG4, we specialize in Texas Instruments all series electronic components. SN75LBC172A16DWRG4 can be shipped within 24 hours after order. If you have any demands for SN75LBC172A16DWRG4, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SN75LBC172A16DWRG4 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SN75LBC172A16DWRG4
| Internal Part Number | EIS-SN75LBC172A16DWRG4 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 2,000 | |
| Category | Integrated Circuits (ICs) | |
| Family | Interface - Drivers, Receivers, Transceivers | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Type | Driver | |
| Protocol | RS422, RS485 | |
| Number of Drivers/Receivers | 4/0 | |
| Duplex | - | |
| Receiver Hysteresis | - | |
| Data Rate | 30Mbps | |
| Voltage - Supply | 4.75 V ~ 5.25 V | |
| Operating Temperature | 0°C ~ 70°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 16-SOIC (0.295", 7.50mm Width) | |
| Supplier Device Package | 16-SOIC | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SN75LBC172A16DWRG4 | |
| Related Links | SN75LBC17, SN75LBC172A16DWRG4 Datasheet, Texas Instruments Distributor | |
