API Delevan SPD127R-472M
- Mfg. Part Number
- SPD127R-472M
- Manufacturer
- API Delevan
- Product Category
- Fixed Inductors
- Brief Description
- FIXED IND 4.7UH 6.8A 22 MOHM SMD
- Datasheet Download
- SPD127R-472M.pdf
Availability of SPD127R-472M
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.76000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SPD127R-472M, we specialize in API Delevan all series electronic components. SPD127R-472M can be shipped within 24 hours after order. If you have any demands for SPD127R-472M, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SPD127R-472M Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SPD127R-472M
| Internal Part Number | EIS-SPD127R-472M | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 500 | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Series | SPD127R | |
| Packaging | Tape & Reel (TR) | |
| Type | Wirewound | |
| Material - Core | Ferrite | |
| Inductance | 4.7µH | |
| Tolerance | ±20% | |
| Current Rating | 6.8A | |
| Current - Saturation | 6.8A | |
| Shielding | Shielded | |
| DC Resistance (DCR) | 22 mOhm Max | |
| Q @ Freq | - | |
| Frequency - Self Resonant | - | |
| Operating Temperature | -55°C ~ 125°C | |
| Frequency - Test | 100kHz | |
| Mounting Type | Surface Mount | |
| Package / Case | Nonstandard | |
| Size / Dimension | 0.472" L x 0.472" W (12.00mm x 12.00mm) | |
| Height - Seated (Max) | 0.315" (8.00mm) | |
| Supplier Device Package | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SPD127R-472M | |
| Related Links | SPD127, SPD127R-472M Datasheet, API Delevan Distributor | |
SPD127R-472M Details Description
