JST Sales America Inc. SPF-01T-2.5C
- Mfg. Part Number
- SPF-01T-2.5C
- Manufacturer
- JST Sales America Inc.
- Product Category
- Terminals - Barrel, Bullet Connectors
- Brief Description
- CONN TERM SPF CRIMP 24-20AWG
- Datasheet Download
- SPF-01T-2.5C.pdf
Availability of SPF-01T-2.5C
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.03236
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SPF-01T-2.5C, we specialize in JST Sales America Inc. all series electronic components. SPF-01T-2.5C can be shipped within 24 hours after order. If you have any demands for SPF-01T-2.5C, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SPF-01T-2.5C Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SPF-01T-2.5C
| Internal Part Number | EIS-SPF-01T-2.5C | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 10,000 | |
| Category | Connectors, Interconnects | |
| Family | Terminals - Barrel, Bullet Connectors | |
| Series | SPF | |
| Packaging | Tape & Reel (TR) | |
| Terminal Type | Female, Receptacle (Socket) | |
| Diameter - Barrel | 0.130" (3.30mm) | |
| Wire Gauge | 20-24 AWG | |
| Length - Overall | 0.614" (15.60mm) | |
| Length - Barrel | 0.287" (7.30mm) | |
| Insulation | Non-Insulated | |
| Termination | Crimp | |
| Features | - | |
| Contact Material | Brass | |
| Contact Finish | Tin | |
| Color | - | |
| Insulation Diameter | 0.063" ~ 0.106" (1.60mm ~ 2.69mm) | |
| Material - Insulation | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SPF-01T-2.5C | |
| Related Links | SPF-01, SPF-01T-2.5C Datasheet, JST Sales America Inc. Distributor | |
