ST SPWF01SC.11
- Mfg. Part Number
- SPWF01SC.11
- Manufacturer
- ST
- Product Category
- RF Transceiver Modules
- Brief Description
- MOD WI-FI UFL 1.5MB FLASH
- Datasheet Download
- SPWF01SC.11.pdf
Availability of SPWF01SC.11
Available Quantity
5482 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 12.02800
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SPWF01SC.11, we specialize in ST all series electronic components. SPWF01SC.11 can be shipped within 24 hours after order. If you have any demands for SPWF01SC.11, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SPWF01SC.11 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SPWF01SC.11
| Internal Part Number | EIS-SPWF01SC.11 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Internet of Things and the ST Portfolio of Wireless Modules Dynamic NFC / RFID Tag | |
| Design Resources | Development Tool Selector | |
| Standard Package | 60 | |
| Category | RF/IF and RFID | |
| Family | RF Transceiver Modules | |
| Series | - | |
| Packaging | Tray | |
| RF Family/Standard | WiFi | |
| Protocol | 802.11b/g/n | |
| Modulation | - | |
| Frequency | 2.4GHz | |
| Data Rate | 54Mbps | |
| Power - Output | 18.3dBm | |
| Sensitivity | -96dBm | |
| Serial Interfaces | UART | |
| Antenna Type | Not Included, U.FL | |
| Memory Size | 1.5MB Flash, 64kB RAM | |
| Voltage - Supply | 3.3V | |
| Current - Receiving | 105mA | |
| Current - Transmitting | 243mA | |
| Mounting Type | Surface Mount | |
| Operating Temperature | -40°C ~ 85°C | |
| Package / Case | Module | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SPWF01SC.11 | |
| Related Links | SPWF0, SPWF01SC.11 Datasheet, ST Distributor | |
SPWF01SC.11 Details Description
