Vishay Semiconductor/Diodes Division SS25-E3/52T
- Mfg. Part Number
- SS25-E3/52T
- Manufacturer
- Vishay Semiconductor/Diodes Division
- Product Category
- Diodes, Rectifiers - Single
- Brief Description
- DIODE SCHOTTKY 50V 2A DO214AA
- Datasheet Download
- SS25-E3/52T.pdf
Availability of SS25-E3/52T
Available Quantity
8020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.09613
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SS25-E3/52T, we specialize in Vishay Semiconductor/Diodes Division all series electronic components. SS25-E3/52T can be shipped within 24 hours after order. If you have any demands for SS25-E3/52T, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SS25-E3/52T Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SS25-E3/52T
| Internal Part Number | EIS-SS25-E3/52T | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 750 | |
| Category | Discrete Semiconductor Products | |
| Family | Diodes, Rectifiers - Single | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Diode Type | Schottky | |
| Voltage - DC Reverse (Vr) (Max) | 50V | |
| Current - Average Rectified (Io) | 2A | |
| Voltage - Forward (Vf) (Max) @ If | 700mV @ 2A | |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) | |
| Reverse Recovery Time (trr) | - | |
| Current - Reverse Leakage @ Vr | 400µA @ 50V | |
| Capacitance @ Vr, F | - | |
| Mounting Type | Surface Mount | |
| Package / Case | DO-214AA, SMB | |
| Supplier Device Package | DO-214AA (SMB) | |
| Operating Temperature - Junction | -65°C ~ 125°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SS25-E3/52T | |
| Related Links | SS25-, SS25-E3/52T Datasheet, Vishay Semiconductor/Diodes Division Distributor | |
SS25-E3/52T Details Description
