Omron SSG-01L1T
- Mfg. Part Number
- SSG-01L1T
- Manufacturer
- Omron
- Product Category
- Snap Action, Limit Switches
- Brief Description
- SWITCH SUBMINI SPDT .1A HNGE LVR
- Datasheet Download
- SSG-01L1T.pdf
Availability of SSG-01L1T
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.86810
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SSG-01L1T, we specialize in Omron all series electronic components. SSG-01L1T can be shipped within 24 hours after order. If you have any demands for SSG-01L1T, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SSG-01L1T Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SSG-01L1T
| Internal Part Number | EIS-SSG-01L1T | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | How to Read Date Codes | |
| Product Training Modules | Snap Switches | |
| Standard Package | 100 | |
| Category | Switches | |
| Family | Snap Action, Limit Switches | |
| Series | SSG | |
| Packaging | Bulk | |
| Circuit | SPDT | |
| Switch Function | On-Mom | |
| Current Rating | 100mA (AC/DC) | |
| Voltage Rating - AC | 125V | |
| Voltage Rating - DC | 30V | |
| Actuator Type | Lever, Straight | |
| Mounting Type | Chassis Mount | |
| Termination Style | Quick Connect - 0.110" (2.8mm) | |
| Ingress Protection | IP40 | |
| Features | - | |
| Operating Force, Torque | 61gf | |
| Release Force | 6gf | |
| Pretravel | - | |
| Differential Travel | 0.031" (0.8mm) | |
| Overtravel | 0.040" (1.0mm) | |
| Operating Position | 0.345" (8.8mm) | |
| Mechanical Life | 10,000,000 Cycles | |
| Electrical Life | 200,000 Cycles | |
| Operating Temperature | -25°C ~ 125°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SSG-01L1T | |
| Related Links | SSG-, SSG-01L1T Datasheet, Omron Distributor | |
SSG-01L1T Details Description
