Panasonic Electric Works ST2-L2-DC3V
- Mfg. Part Number
- ST2-L2-DC3V
- Manufacturer
- Panasonic Electric Works
- Product Category
- Power Relays, Over 2 Amps
- Brief Description
- RELAY GENERAL PURPOSE DPST 8A 3V
- Datasheet Download
- ST2-L2-DC3V.pdf
Availability of ST2-L2-DC3V
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ST2-L2-DC3V, we specialize in Panasonic Electric Works all series electronic components. ST2-L2-DC3V can be shipped within 24 hours after order. If you have any demands for ST2-L2-DC3V, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ST2-L2-DC3V Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ST2-L2-DC3V
| Internal Part Number | EIS-ST2-L2-DC3V | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | General Appl Guidelines Standards Chart How to Read Date Codes | |
| Standard Package | 50 | |
| Category | Relays | |
| Family | Power Relays, Over 2 Amps | |
| Series | ST | |
| Packaging | Tube | |
| Relay Type | General Purpose | |
| Coil Type | Latching, Dual Coil | |
| Coil Current | 75mA | |
| Coil Voltage | 3VDC | |
| Contact Form | DPST (2 Form A) | |
| Contact Rating (Current) | 8A | |
| Switching Voltage | 380VAC, 250VDC - Max | |
| Turn On Voltage (Max) | 2.4 VDC | |
| Turn Off Voltage (Min) | - | |
| Operate Time | 10ms | |
| Release Time | 10ms | |
| Features | Sealed - Fully | |
| Mounting Type | Through Hole | |
| Termination Style | PC Pin | |
| Contact Material | Silver Alloy | |
| Coil Power | 240 mW | |
| Coil Resistance | 40 Ohms | |
| Operating Temperature | -40°C ~ 60°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ST2-L2-DC3V | |
| Related Links | ST2-L, ST2-L2-DC3V Datasheet, Panasonic Electric Works Distributor | |
ST2-L2-DC3V Details Description
