ST STPR820D
- Mfg. Part Number
- STPR820D
- Manufacturer
- ST
- Product Category
- Diodes, Rectifiers - Single
- Brief Description
- DIODE GEN PURP 200V 8A TO220AC
- Datasheet Download
- STPR820D.pdf
Availability of STPR820D
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of STPR820D, we specialize in ST all series electronic components. STPR820D can be shipped within 24 hours after order. If you have any demands for STPR820D, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- STPR820D Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
STPR820D
| Internal Part Number | EIS-STPR820D | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 50 | |
| Category | Discrete Semiconductor Products | |
| Family | Diodes, Rectifiers - Single | |
| Series | - | |
| Packaging | Tube | |
| Diode Type | Standard | |
| Voltage - DC Reverse (Vr) (Max) | 200V | |
| Current - Average Rectified (Io) | 8A | |
| Voltage - Forward (Vf) (Max) @ If | 1.25V @ 16A | |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) | |
| Reverse Recovery Time (trr) | 30ns | |
| Current - Reverse Leakage @ Vr | 50µA @ 200V | |
| Capacitance @ Vr, F | - | |
| Mounting Type | Through Hole | |
| Package / Case | TO-220-2 | |
| Supplier Device Package | TO-220AC | |
| Operating Temperature - Junction | 150°C (Max) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | STPR820D | |
| Related Links | STPR, STPR820D Datasheet, ST Distributor | |
STPR820D Details Description
