ST STTH3R04RL
- Mfg. Part Number
- STTH3R04RL
- Manufacturer
- ST
- Product Category
- Diodes, Rectifiers - Single
- Brief Description
- DIODE GEN PURP 400V 3A DO201AD
- Datasheet Download
- STTH3R04RL.pdf
Availability of STTH3R04RL
Available Quantity
6920 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.18000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of STTH3R04RL, we specialize in ST all series electronic components. STTH3R04RL can be shipped within 24 hours after order. If you have any demands for STTH3R04RL, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- STTH3R04RL Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
STTH3R04RL
| Internal Part Number | EIS-STTH3R04RL | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | STTH3R04 View All Specifications | |
| Standard Package | 1,900 | |
| Category | Discrete Semiconductor Products | |
| Family | Diodes, Rectifiers - Single | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Diode Type | Standard | |
| Voltage - DC Reverse (Vr) (Max) | 400V | |
| Current - Average Rectified (Io) | 3A | |
| Voltage - Forward (Vf) (Max) @ If | 1.5V @ 3A | |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) | |
| Reverse Recovery Time (trr) | 35ns | |
| Current - Reverse Leakage @ Vr | 5µA @ 400V | |
| Capacitance @ Vr, F | - | |
| Mounting Type | Through Hole | |
| Package / Case | DO-201AD, Axial | |
| Supplier Device Package | DO-201AD | |
| Operating Temperature - Junction | 175°C (Max) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | STTH3R04RL | |
| Related Links | STTH3, STTH3R04RL Datasheet, ST Distributor | |
