Microchip Technology TC1303B-SP0EMFTR
- Mfg. Part Number
- TC1303B-SP0EMFTR
- Manufacturer
- Microchip Technology
- Product Category
- PMIC - Voltage Regulators - Linear + Switching
- Brief Description
- IC REG DL BUCK/LINEAR SYNC 10DFN
- Datasheet Download
- TC1303B-SP0EMFTR.pdf
Availability of TC1303B-SP0EMFTR
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.96000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TC1303B-SP0EMFTR, we specialize in Microchip Technology all series electronic components. TC1303B-SP0EMFTR can be shipped within 24 hours after order. If you have any demands for TC1303B-SP0EMFTR, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TC1303B-SP0EMFTR Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TC1303B-SP0EMFTR
| Internal Part Number | EIS-TC1303B-SP0EMFTR | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Design/Specification | Mold Compound Update 18/Feb/2015 | |
| PCN Packaging | Label and Packing Changes 23/Sep/2015 | |
| Standard Package | 3,300 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Voltage Regulators - Linear + Switching | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Topology | Step-Down (Buck) Synchronous (1), Linear (LDO) (1) | |
| Function | Any Function | |
| Number of Outputs | 2 | |
| Frequency - Switching | 2MHz | |
| Voltage/Current - Output 1 | 1.5V, 500mA | |
| Voltage/Current - Output 2 | 1.8V, 300mA | |
| Voltage/Current - Output 3 | - | |
| w/LED Driver | No | |
| w/Supervisor | No | |
| w/Sequencer | Yes | |
| Voltage - Supply | 2.7 V ~ 5.5 V | |
| Operating Temperature | -40°C ~ 85°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 10-VFDFN Exposed Pad | |
| Supplier Device Package | 10-DFN (3x3) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TC1303B-SP0EMFTR | |
| Related Links | TC1303B-, TC1303B-SP0EMFTR Datasheet, Microchip Technology Distributor | |
