Microchip Technology TC4420IJA
- Mfg. Part Number
- TC4420IJA
- Manufacturer
- Microchip Technology
- Product Category
- PMIC - Gate Drivers
- Brief Description
- IC MOSFET DRIVER 6A HS 8CDIP
- Datasheet Download
- TC4420IJA.pdf
Availability of TC4420IJA
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 8.64000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TC4420IJA, we specialize in Microchip Technology all series electronic components. TC4420IJA can be shipped within 24 hours after order. If you have any demands for TC4420IJA, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TC4420IJA Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TC4420IJA
| Internal Part Number | EIS-TC4420IJA | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Assembly/Origin | Qualification Epoxy Die 09/Sep/2014 | |
| PCN Packaging | Label and Packing Changes 23/Sep/2015 | |
| Standard Package | 56 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Gate Drivers | |
| Series | - | |
| Packaging | Tube | |
| Configuration | Low-Side | |
| Input Type | Non-Inverting | |
| Delay Time | 55ns | |
| Current - Peak | 6A | |
| Number of Configurations | 1 | |
| Number of Outputs | 1 | |
| High Side Voltage - Max (Bootstrap) | - | |
| Voltage - Supply | 4.5 V ~ 18 V | |
| Operating Temperature | -25°C ~ 85°C | |
| Mounting Type | Through Hole | |
| Package / Case | 8-CDIP (0.300", 7.62mm) | |
| Supplier Device Package | 8-CERDIP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TC4420IJA | |
| Related Links | TC44, TC4420IJA Datasheet, Microchip Technology Distributor | |
