Microchip Technology TC7107CPL
- Mfg. Part Number
- TC7107CPL
- Manufacturer
- Microchip Technology
- Product Category
- PMIC - Display Drivers
- Brief Description
- IC ADC 3 1/2DGT LED DVR 40-DIP
- Datasheet Download
- TC7107CPL.pdf
Availability of TC7107CPL
Available Quantity
5132 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 3.20000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TC7107CPL, we specialize in Microchip Technology all series electronic components. TC7107CPL can be shipped within 24 hours after order. If you have any demands for TC7107CPL, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TC7107CPL Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TC7107CPL
| Internal Part Number | EIS-TC7107CPL | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Design/Specification | PdCu Bond Wire Update 21/Sep/2015 | |
| PCN Assembly/Origin | Qualification PDIP-28L/40L 21/Oct/2013 Qualification Assembly Site PDIP-28/40L 23/Aug/2013 Qualification Revision 06/Feb/2014 Assembly Site Transfer 13/May/2015 | |
| PCN Packaging | Label and Packing Changes 23/Sep/2015 | |
| Standard Package | 10 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Display Drivers | |
| Series | - | |
| Packaging | Tube | |
| Display Type | LED | |
| Configuration | 7 Segment | |
| Interface | - | |
| Digits or Characters | A/D 3.5 Digits | |
| Current - Supply | 800µA | |
| Voltage - Supply | 5V | |
| Operating Temperature | 0°C ~ 70°C | |
| Mounting Type | Through Hole | |
| Package / Case | 40-DIP (0.600", 15.24mm) | |
| Supplier Device Package | 40-PDIP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TC7107CPL | |
| Related Links | TC71, TC7107CPL Datasheet, Microchip Technology Distributor | |
