ST TDA7563ASMTR
- Mfg. Part Number
- TDA7563ASMTR
- Manufacturer
- ST
- Product Category
- Linear - Amplifiers - Audio
- Brief Description
- IC AMP QUAD MULTIFUNC FLEXIWATT2
- Datasheet Download
- TDA7563ASMTR.pdf
Availability of TDA7563ASMTR
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 8.21500
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TDA7563ASMTR, we specialize in ST all series electronic components. TDA7563ASMTR can be shipped within 24 hours after order. If you have any demands for TDA7563ASMTR, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TDA7563ASMTR Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TDA7563ASMTR
| Internal Part Number | EIS-TDA7563ASMTR | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | TDA7563A View All Specifications | |
| Standard Package | 300 | |
| Category | Integrated Circuits (ICs) | |
| Family | Linear - Amplifiers - Audio | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Type | Class AB | |
| Output Type | 4-Channel (Quad) | |
| Max Output Power x Channels @ Load | 75W x 4 @ 2 Ohm | |
| Voltage - Supply | 8 V ~ 18 V | |
| Features | I²C, Mute, Short-Circuit and Thermal Protection, Standby | |
| Mounting Type | Surface Mount | |
| Operating Temperature | -55°C ~ 150°C (TJ) | |
| Supplier Device Package | 27-Flexiwatt (SMD) | |
| Package / Case | 27-Flexiwatt (Formed Leads) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TDA7563ASMTR | |
| Related Links | TDA756, TDA7563ASMTR Datasheet, ST Distributor | |
TDA7563ASMTR Details Description
