Texas Instruments THS1040CDWG4
- Mfg. Part Number
- THS1040CDWG4
- Manufacturer
- Texas Instruments
- Product Category
- Data Acquisition - Analog to Digital Converters (ADC)
- Brief Description
- IC ADC 10BIT 40MSPS LP 28-SOIC
- Datasheet Download
- THS1040CDWG4.pdf
Availability of THS1040CDWG4
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of THS1040CDWG4, we specialize in Texas Instruments all series electronic components. THS1040CDWG4 can be shipped within 24 hours after order. If you have any demands for THS1040CDWG4, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- THS1040CDWG4 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
THS1040CDWG4
| Internal Part Number | EIS-THS1040CDWG4 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 20 | |
| Category | Integrated Circuits (ICs) | |
| Family | Data Acquisition - Analog to Digital Converters (ADC) | |
| Series | - | |
| Packaging | Tube | |
| Number of Bits | 10 | |
| Sampling Rate (Per Second) | 40M | |
| Number of Inputs | 1 | |
| Input Type | Differential, Single Ended | |
| Data Interface | Parallel | |
| Configuration | S/H-ADC | |
| Ratio - S/H:ADC | 1:1 | |
| Number of A/D Converters | 1 | |
| Architecture | Pipelined | |
| Reference Type | External, Internal | |
| Voltage - Supply, Analog | 3 V ~ 3.6 V | |
| Voltage - Supply, Digital | 3 V ~ 3.6 V | |
| Features | - | |
| Operating Temperature | 0°C ~ 70°C | |
| Package / Case | 28-SOIC (0.295", 7.50mm Width) | |
| Supplier Device Package | 28-SOIC | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | THS1040CDWG4 | |
| Related Links | THS104, THS1040CDWG4 Datasheet, Texas Instruments Distributor | |
THS1040CDWG4 Details Description
