Toshiba Semiconductor & Storage TK3A60DA(STA4,Q,M)
- Mfg. Part Number
- TK3A60DA(STA4,Q,M)
- Manufacturer
- Toshiba Semiconductor & Storage
- Product Category
- FETs - Single
- Brief Description
- MOSFET N-CH 600V 2.5A TO-220SIS
- Datasheet Download
- TK3A60DA(STA4,Q,M).pdf
Availability of TK3A60DA(STA4,Q,M)
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.97720
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TK3A60DA(STA4,Q,M), we specialize in Toshiba Semiconductor & Storage all series electronic components. TK3A60DA(STA4,Q,M) can be shipped within 24 hours after order. If you have any demands for TK3A60DA(STA4,Q,M), Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TK3A60DA(STA4,Q,M) Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TK3A60DA(STA4,Q,M)
| Internal Part Number | EIS-TK3A60DA(STA4,Q,M) | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 50 | |
| Category | Discrete Semiconductor Products | |
| Family | FETs - Single | |
| Series | - | |
| Packaging | Tube | |
| FET Type | MOSFET N-Channel, Metal Oxide | |
| FET Feature | Standard | |
| Drain to Source Voltage (Vdss) | 600V | |
| Current - Continuous Drain (Id) @ 25°C | 2.5A (Ta) | |
| Rds On (Max) @ Id, Vgs | 2.8 Ohm @ 1.3A, 10V | |
| Vgs(th) (Max) @ Id | 4.4V @ 1mA | |
| Gate Charge (Qg) @ Vgs | 9nC @ 10V | |
| Input Capacitance (Ciss) @ Vds | 380pF @ 25V | |
| Power - Max | 30W | |
| Mounting Type | Through Hole | |
| Package / Case | TO-220-3 Full Pack | |
| Supplier Device Package | TO-220SIS | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TK3A60DA(STA4,Q,M) | |
| Related Links | TK3A60DA(, TK3A60DA(STA4,Q,M) Datasheet, Toshiba Semiconductor & Storage Distributor | |
TK3A60DA(STA4,Q,M) Details Description
