Texas Instruments TL4050A10QDBZT
- Mfg. Part Number
- TL4050A10QDBZT
- Manufacturer
- Texas Instruments
- Product Category
- PMIC - Voltage Reference
- Brief Description
- IC VREF SHUNT 10V SOT23-3
- Datasheet Download
- TL4050A10QDBZT.pdf
Availability of TL4050A10QDBZT
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TL4050A10QDBZT, we specialize in Texas Instruments all series electronic components. TL4050A10QDBZT can be shipped within 24 hours after order. If you have any demands for TL4050A10QDBZT, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TL4050A10QDBZT Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TL4050A10QDBZT
| Internal Part Number | EIS-TL4050A10QDBZT | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 250 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Voltage Reference | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Reference Type | Shunt | |
| Output Type | Fixed | |
| Voltage - Output (Min/Fixed) | 10V | |
| Voltage - Output (Max) | - | |
| Current - Output | 15mA | |
| Tolerance | ±0.1% | |
| Temperature Coefficient | 50ppm/°C | |
| Noise - 0.1Hz to 10Hz | - | |
| Noise - 10Hz to 10kHz | 150µVrms | |
| Voltage - Input | - | |
| Current - Supply | - | |
| Current - Cathode | 110µA | |
| Operating Temperature | -40°C ~ 125°C (TA) | |
| Mounting Type | Surface Mount | |
| Package / Case | TO-236-3, SC-59, SOT-23-3 | |
| Supplier Device Package | SOT-23-3 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TL4050A10QDBZT | |
| Related Links | TL4050A, TL4050A10QDBZT Datasheet, Texas Instruments Distributor | |
TL4050A10QDBZT Details Description
